- Supports Coaxial, Optical, USB and 4 HDMI inputs
- Supports HDMI, Coaxial and Optical outputs
- Support digital audio signal input and conversion into analog stereo
- Support HDMI Audio output can either output the incoming embedded HDMI (Bypass Mode) or insert the selected audio signal (Ext Audio Mode)
- HDMI video always bypassed to HDMI output
- Support HDMI video resolutions up to 4K2K (3840×2160@24/25/30/50/60 and 4096×2160@24/25/30/50/60Hz)
- Support HDMI data rate up to 6Gbps and ‘Deep Color’ up to 1080p at 36-bit
- Support Coaxial and Optical input sampling rate up to 384kHz at 32-bit
- Coaxial and Optical input support DOP decode to PCM
- Support headphone output volume control
- Support Sampling Rate Conversion, all inputs can be SRC to 44.1, 48, 88.2, 96, 176.4, 192 and 384kHz via DSP engine
- Supports L/R input/output, XLR and 6.3mm headphone outputs
- Supports analog audio signal input converts into digital signal output
- Control by remote control and on-panel wheel
- HDMI audio embedding or de-embedding
- Headphone output volume control over main control dial or remote control
- Direct power and mute button on unit
- High viewing angle OLED display
- Headphone output fades in after system is muted
- Note: USB Audio support in Windows requires the installation of USB Audio drivers (available on the included CD). USB Audio support in MacOS X is built in and does not require drivers to be installed. DOP via USB is supported in both Windows and MacOS X.
Inputs
- 4x HDMI [4x Uncompressed AV and Data]
- 1x TOSLINK [1x OPTICAL 2 Channel LPCM]
- 1x RCA [1x COAX 2 Channel LPCM]
- 1x USB Type B [1x USB (2.0) Audio]
- 1x 3.5mm Stereo Mini-jack [1x Stereo(L/R)]
Outputs
- 1x HDMI [1x Uncompressed AV and Data]
- 1x TOSLINK [1x OPTICAL 2 Channel LPCM]
- 1x RCA [1x COAX 2 Channel LPCM]
- 2x RCA [1x Stereo (L/R)]
- 1x 6.35mm Stereo Jack [1x Headphone]
- 2x XLR [1x Stereo (Balanced)]
PSU:
- 5V/3A
Dimensions
- 223mm [W] x 145mm [D] x 48mm [H]
Net Weight
- 886g
