- Supports coaxial and optical digital audio inputs
- Supports simultaneous coaxial and optical digital audio outputs
- Supports DSD stream audio passthrough
- Supports LPCM input sampling rates up to 192kHz
- Supports conversion of the sampling rate of the audio input up to a maximum sampling rate of 192kHz/24-bit
- Supports De-pop function to eliminate unwanted ‘popping’ noises on plug in of audio source
- Supports DSD over PCM (DOP) decoding to PCM of coaxial and optical audio source
- Supports volume control, the minimum volume control can be reduced to -60dB
- Supports firmware update via micro USB
- Compact and light weight design
Inputs
- 1x TOSLINK [1x OPTICAL 2 Channel LPCM / Dolby Digital / DTS]
- 1x RCA [1x COAX 2 Channel LPCM / Dolby Digital / DTS]
- 1x USB Mini-B [1x SERVICE Propriety Data]
Outputs
- 1x TOSLINK [1x OPTICAL 2 Channel LPCM / Dolby Digital / DTS]
- 1x RCA [1x COAX 2 Channel LPCM / Dolby Digital / DTS]
PSU:
- 5V/2.6A
Dimensions
- 51mm [W] x 22mm [D] x 98mm [H]
Net Weight
- 61g
