- Supports digital-to-analog audio conversion (DAC) and analog-to-digital audio conversion (ADC)
- Supports input sampling rates up to 96kHz and output at 48kHz
- Supports 2 passive speaker outputs with 4Ω to 8Ω impedance each
- Speaker output supports 45W/4Ω per channel
- Hi-Efficient 2x45W class D amplification, with efficiency higher than 80%
- Simultaneous sound output on both digital and analog connections
- Supports distances up to 300 meters through industry standard CAT5e/6/7 cables
- Supports control via RS-232, IP (Telnet and WebGUI), IR and on-panel controls
- Sound amplification up to -80dB with volume up moderation at power on
Inputs
- 1x TOSLINK [1x OPTICAL 2 Channel LPCM]
- 1x RCA [1x COAXIAL 2 Channel LPCM]
- 2x RCA [1x Stereo (L/R)]
- 1x 3.5mm Stereo Mini-jack [1x LINE IN Stereo(L/R)]
- 1x 3.5mm Stereo Mini-jack [1x Infrared Receiver]
- 1x 9-pin D-sub [1x RS-232 Data]
- 1x RJ45 [1x IP Control]
- 1x USB Type A [1x SERVICE Propriety Data]
- 1x RJ45 [1x AUDIO-CAT Digital Audio Propriety Data / Propriety Data]
Outputs
- 4x Speaker Binding Posts [1x Speaker Level Stereo Output]
PSU:
- 24V/2.7A
Dimensions
- 215mm [W] x 172mm [D] x 46mm [H]
Net Weight
- 1060g
