- Dolby Digital Decoder technology embedded
- DTS 2.0+Digital Out Decoder technology embedded
- Integrated digital interpolator filter and Digital-to-Analog Converter (DAC)
- Supports LPCM input sampling rate up to 96kHz and 2-CH output at 48kHz
- Support Dolby® Digital/DTS® sampling rate up to 48kHz
- Supports simultaneous audio outputs on HDMI, analog R/L, Coaxial and Optical
- HDMI (with 3D & 4K2K supported) and HDCP compliant
- Supports HDTV resolutions up to 4Kx2K (3840×2160@24/25/30, 50/60 YUV_420 & 4096×2160@24, 50/60 YUV_420)
- Supports HDMI data rate from 300Mbps to 3Gbps and ‘Deep Color’ up to 1080p/36-bit
Inputs
- 1x HDMI [1x Uncompressed AV and Data]
- 1x USB Mini-B [1x SERVICE Propriety Data]
Outputs
- 1x HDMI [1x Uncompressed AV and Data]
- 1x TOSLINK [1x Optical 2 Channel LPCM]
- 1x RCA [1x Coaxial 2 Channel LPCM]
- 2x RCA [1x Stereo (L/R)]
PSU:
- 5V/2.6A
Dimensions
- 180mm [W] x 110mm [D] x 25mm [H]
Net Weight
- 368g
