- Supports optical digital audio signal input and conversion into analog audio signal L/R output
- Supports uncompressed digital LPCM stereo or Dolby Digital 5.1CH audio inputs
- Supports LPCM 2CH audio sampling rates from 32 to 96 kHz (32, 44.1, 48, 88.2 and 96 kHz)
- Supports Dolby Digital 5.1CH audio sampling rates of 48 kHz
- Supports Dolby Digital audio downmixing to 2-channel audio
- Supports S/PDIF bitstream 24-bit of data for the left and right channels
- Compact, elegant design and easy to install
Inputs
- 1x TOSLINK [1x OPTICAL 2 Channel LPCM / Dolby Digital]
- 1x USB Mini-B [1x 5V USB Power]
Outputs
- 2x RCA [1x LINE OUT Stereo (L/R)]
PSU:
- USB powered
Dimensions
- 55mm [W] x 82mm [D] x 22mm [H]
Net Weight
- 65g
