For both high-performance distributed audio and exceptional home theater, the EL-800-ICW-8 is the perfect choice for discerning customers. Better clarity, resolution and dynamics are achieved via a graphite-injected polypropylene cone weoofer and a 1″ aluminum dome tweeter. Increased vocal clarity, enhanced dialogue and adjustment of post-installation tweeter performance are enabled with the front-mounted vocal and tweeter enhancement switches.
FEATURES
Dynamic Room Filling Sound
Low Crossover points and a light-weight graphite injected polypropylene cone woofer that’s mounted as close to the surface as possible delivers dynamic sound with the widest dispersion possible
Quick, Responsive Highs
Aluminum dome tweeters are lightweight, strong and respond instantaneously to changes in music or movies
Tilt Tweeter
The tilting tweeter mechanism allows you to direct sound to the listening area and maintains high frequency performance even when the speaker is mounted in less than ideal locations
Vocal and Tweeter Enhancement Switches
Easily adjust tweeter performance or enhance the dialogue in movies via the Vocal and Tweeter Enhancement Swiches
Thin is In
A thin-bezel magnetic grille ensures a secure fit, pleasing aesthetic and with a one-step paint process, it fits universally into almost any décor
Secure Connection
All Nice/ELAN speakers feature spring loaded binding posts that provide a secure, worry-free connection in the wall or ceiling
Lifetime Warranty
Feel confident that All Nice/ELAN Architectural speakers are backed by a limited lifetime warranty
Secure Connection
All Nice/ELAN speakers feature spring loaded binding posts that provide a secure, worry-free connection in the wall or ceiling
Lifetime Warranty
Feel confident that All Nice/ELAN Architectural speakers are backed by a limited lifetime warranty
SPECIFICATIONS
Woofer Size: 8″ / 200mm
Woofer Construction: Graphite Injected Polypropylene Cone
Tweeter: 1″ / 25mm Pivoting Aluminum Dome
Frequency Response: 48Hz-20kHz
Impedance: 8 (Ohms)
Power Handling: 130 (Watts)
Sensitivity: 90 (dB)
Timbre: Timbre-Matched to all 800 Series Speakers
Dimensions: 9.8″ / 249mm Width x 14.6″ / 370mm Height x 4.1″ / 105mm Depth
Hole Cutout Dimensions: 8.75″ / 222.5mm Width x 13.625″ / 346mm Height
Mounting Depth: 4″ / 102mm
OTHER SPECIFICATIONS
General
- Woofer Size6.5 (Inches)
- Shipping Info
- Length16.4 (Inches)
- Width11.9 (Inches)
- Height11.6 (Inches)
- Weight7.56 (Lbs)
- Unit of MeasurePair
- UPC844039014528
Other Specifications
- Woofer Size 8″ / 200mm
- Woofer Construction Graphite Injected Polypropylene Cone
- Tweeter 1″ / 25mm Pivoting Aluminum Dome
- Frequency Response 48Hz-20kHz
- Impedance 8 (Ohms)
- Power Handling 130 (Watts)
- Sensitivity 90 (dB)
- Timbre Timbre-Matched to all 800 Series Speakers
- Dimensions 9.8″ / 249mm Width x 14.6″ / 370mm Height x 4.1″ / 105mm Depth
- Hole Cutout Dimensions 8.75″ / 222.5mm Width x 13.625″ / 346mm Height
- Mounting Depth 4″ / 102mm
