SC12-30
Twelve Channel, Fully Configurable Power Amp; 12 x 30W; Multivoltage

The SC12-30 is a 12-channel, fully configurable power amplifier that provides 30W per channel (80W when bridged) and our unique BusMatrix™ Selector. The SC12-30 is the perfect multi-zone or multi-room solution.

Offering the classic SpeakerCraft stability that you’ve come to know and trust, the powerful SC12-30 will exceed your installation needs. Specifically designed to solve the problems of interfacing with different brands and models of equipment, and different rooms and applications, the SC12-30 makes installation easier and more straight forward than ever before. Fully configurable, with 12-channels that provide 30W per channel (80W when bridged) and our unique BusMatrix™ Selector, the SC12-30 is the perfect multi-zone or multi-room solution.

SPECIFICATIONS

  • 30 watts RMS per channel into 8 Ohms (all channels driven)
  • 40 watts RMS per channel into 4 Ohms (all channels driven)
  • Adjacent channels are bridgable to 80 watts RMS into 8 Ohms (all channels driven)
  • Voltage trigger input accepts 3-24VAC/DC
  • 12-volt control out
  • Removable line cord
  • Rack mount ears included

OTHER SPECIFICATIONS

General
Number of Channels 12
Watts RMS Per Channel 30
Rack Mountable Yes
Rack Ears Included Yes
Dimensions 17.25″ (43.81cm) wide, 5.75″ (14.47cm) high (including feet), 16.25″ (41.11cm) deep
Weight 35 lb. (15.8 kg)
Shipping Info
Length 23.1 (Inches)
Width 19.3 (Inches)
Height 10.1 (Inches)
Weight 40.05 (Lbs)
Unit of Measure Each
UPC 664254999680
Master Pack Qty 2
Other Specifications
30 watts RMS per channel into 8 Ohms (all channels driven)
40 watts RMS per channel into 4 Ohms (all channels driven)
Adjacent channels are bridgable to 80 watts RMS into 8 Ohms (all channels driven)
Voltage trigger input accepts 3-24VAC/DC
12-volt control out
Removable line cord
Rack mount ears included
Two year limited warranty
