- HDMI (with 3D format and 4K2K resolution support), HDCP and DVI compliant
- Supports CEC bypass function
- Contemporaneous transmittal of uncompressed video/audio and data over a single CAT5e/6 cable up to 100 m/328 ft
- Supports uncompressed video up to 4K2K resolution (3840×2160@30 Hz or 4096×2160@24 Hz)
- Supports pass-through of high-definition audio formats: LPCM 7.1CH, Dolby TrueHD and DTS-HD Mater Audio
- HDBaseT™ convergence: uncompressed high-definition Video and Audio, LAN serving, Bi-directionlal Power over Cable (PoC) and IR/RS-232 Control pass-through
- Installation friendly
Inputs
- 1x HDMI [1x Uncompressed AV and Data]
- 1x RJ45 [1x LAN Serving]
- 1x 9-pin D-sub [1x RS-232 Data]
- 1x 3.5mm Stereo Mini-jack [1x Infrared Receiver]
Outputs
- 1x RJ45 [1x HDMI & Propriety Data]
- 1x 3.5mm Stereo Mini-jack [1x Infrared Emitter]
PSU:
- 24V/1.25A
Dimensions
- 102mm [W] x 120mm [D] x 25mm [H]
Net Weight
- 252gr
