- Video, audio and control reception over TCP/IP in Unicast (point-to-point) or Multicast (single-to-many, many-to-many) modes
- Support video wall with 180° and 270° rotation
- Video output can be scaled to a selected resolution, or left unscaled
- The analog Line In on a connected Transmitter will send audio directly to this Receiver’s analog Line Out as well as being embedded into the HDMI output signal
- The Mic In on the Receiver sends audio directly to the analog Line Out on the Transmitter
- May be powered directly by PoE when connected to a Gigabit Ethernet switch that provides PoE (802.3af)
- Includes 3 LAN ports, allowing multiple Receivers to be daisy chained without the need for an external Gigabit Ethernet switch
- Supports USB keyboard, mouse and storage extension
Interfaces
Input Port
1 Analog Mono (3.5mm)
Output Port
1 HDMI (Type-A)
1 VGA (HD-15)
1 S/PDIF (TOSLINK)
1 Analog Stereo (3.5mm)
Bi-directional Port
3 GbE LAN (RJ-45)
Control I/O
1 IR Extender (3.5mm)
1 IR Blaster (3.5mm)
1 RS-232 (DB-9)
4 USB (Type-A)
Video
HDMI Compliance
HDMI 2.0 (DVI 1.0)
HDCP Compliance
2.X
Input Signal Type
4096x2160p@60 8bit YUV4:2:0
Output Signal Type
4096x2160p@30 8bit RGB
Resolutions
Maximum Input
LAN (Streaming)
4096×2160p@30
Maximum Output
HDMI
4096×2160p@30
VGA
1920×1200p@60RB
Audio
Digital Formats
HDMI
LPCM (8 Channels), Bitstream, High Bit Rate Bitstream
Line Out / Optical Out
LPCM (2 Channels), Bitstream
Line Level
Mic In
300 mVrms, S/N Ratio: > 80dB (1kHz with 0dBFS)
Line Out
2 Vrms, S/N Ratio: > 80dB (1kHz with 0dBFS)
