4 HDBase-T output ports paired with IR output and analog stereo output ports
Supports 4K HDR at 24Hz (4:4:4) and 60Hz (YUV 4:2:0) with up to 12- bit color
Supports 12-bit Deep Color up to 1080p@60Hz
Supports pass-through of audio formats including LPCM 2.0/5.1/7.1 Bitstream, and HD Bitstream
This card’s features are controlled by the modular matrix
Interfaces
Input Port
4 HDBT (RJ-45)
4 Stereo analog audio (3.5mm)
Control I/O
4 IR Blaster (3.5mm)
Video
HDMI Compliance
HDBT 4K@30
HDCP Compliance
2.X
Input Signal Type
4096x2160p@60 8bit YUV 4:2:0
Resolutions
Maximum Input HDBT
4096×2160p@60 YUV 4:2:0
Audio
HDBT
LPCM (8 Channels), Bitstream, High Bit Rate Bitstream
Audio Out
Frequency Response: < ±1dB (20Hz to 20kHz)
THD: < 0.01% (20Hz to 20kHz) S/N Ratio: > 70dB (1kHz with 0dBFS)
Crosstalk: < −60dB (10kHz, Vin=0dBFS)
