- Compatible with HDMI, HDCP 1.1
- Supports resolutions VGA-WUXGA, 4K2K@24/25/30 & YUV_420 and 480i-1080p depends on the output display’s EDID settings
- Distance up to 60 meters over CAT6/7 cables
- Supports 3D signal display depends on the output display EDID settings
- Supports PoC (Power over Cable) on compatible receivers only
- HDMI Input up to 15 meters at 8-bit resolution or 10 meters at 12-bit resolution
- Supports bi-directional IR from input and output locations
- RS-232 control
- Remote control, on-panel control and IP Control (Telnet & Web GUI)
- Supports external and internal EDID settings
- Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio transmission
Inputs
- 8x HDMI [8x Uncompressed AV and Data]
- 8x 3.5mm Stereo Mini-jack [8x Infrared Receiver]
- 1x 3.5mm Stereo Mini-jack [1x IR ALL Infrared Receiver]
- 1x RJ45 [1x IP Control]
- 1x 9-pin D-sub [1x RS-232 Data]
- 1x USB Mini-B [1x SERVICE Proprietary Data]
Outputs
- 8x RJ45 [8x HDMI & Proprietary Data]
- 8x 3.5mm Stereo Mini-jack [8x Infrared Emitter]
- 1x 3.5mm Stereo Mini-jack [1x IR ALL Infrared Emitter]
PSU:
- 24V/6.25A
Dimensions
- 438mm [W] x 249mm [D] x 93mm [H]
Net Weight
- 4402gr
