- Compatible with HDMI, HDCP 1.1
- Supports resolutions VGA-WUXGA and 480i-1080p/4K2K depends on the output display’s EDID settings
- Supports 3D signal display depends on the output display EDID settings
- Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio transmission
- Supports distances up to 100 meters through CAT6/7 cables
- Supports HDMI input up to 15 meters at 8-bit resolution or 10 meters at 12-bit resolution
- Supports LAN serving function through the LAN port and PoE (Power over Ethernet) on compatible receivers only
- Supports bi-directional IR from input and output locations
- Control of the matrix via RS-232, remote control, on-panel control and IP Control (Telnet & Web GUI)
- Supports external and internal EDID settings
Inputs
- 8x HDMI [8x Uncompressed AV and Data]
- 8x 3.5mm Stereo Mini-jack [8x Infrared Receiver]
- 1x 3.5mm Stereo Mini-jack [1x ALL Infrared Receiver]
- 1x 9-pin D-sub [1x RS-232 Data]
- 1x RJ45 [1x IP Control / LAN Serving]
- 1x USB Mini-B [1x SERVICE Propriety Data]
Outputs
- 8x RJ45 [8x HDMI & Propriety Data]
- 8x 3.5mm Stereo Mini-jack [8x Infrared Emitter]
- 1x 3.5mm Stereo Mini-jack [1x ALL Infrared Emitter]
PSU:
- 24V/6.25A
Dimensions
- 436mm [W] x 255mm [D] x 48mm [H]
Net Weight
- 4350gr
