- Supports UHD resolutions up to 4K2K@24/25/30Hz & 4K2K YUV420@60Hz
- Supports HDTV resolutions up to 1080@60Hz, ‘Deep Color’ 36/30/24-bit and PC resolutions up to WUXGA@60Hz(RB)
- Supports 3D
- Supports pass-through of audio formats: LPCM 2/5.1/7.1CH, Dolby Digital 2~5.1CH, DTS 2~5.1CH, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio
- Supports EDID option function
- Supports control via IR, RS-232, Telnet and WebGUI
- Input port HDCP support Standard and Apple mode (The Apple mode selection to guarantees the use of Apple tools)
- Coherent with DVI source
Inputs
- 10x HDMI [10x Uncompressed AV and Data]
- 1x 3.5mm Stereo Mini-jack [1x Infrared Receiver]
- 1x 9-pin D-sub [1x RS-232 Data]
- 1x RJ45 [1x IP Control]
- 1x USB Type A [1x SERVICE Propriety Data]
Outputs
- 2x HDMI [2x Uncompressed AV and Data]
PSU:
- 5V/2.6A
Dimensions
- 482mm [W] x 276mm [D] x 52mm [H]
Net Weight
- 2854gr
