- Video Bandwidth: 225MHz/6.25Gbps
- HDBaseT technology: IR/RS-232 functions
- Output Ports: 8 CAT5e/6/7, 8 IR Extender, and 8 IR Blaster
- Supported PC Resolutions: VGA to WUXGA
- Supported HD Resolutions: 480i to 1080p
- IR Frequency: 30~50Hz
- Supported Audio transmission: LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus, and DTS-HD Master Audio
- Supported Audio sampling rate: 32~192kHz
Inputs
- 8x 3.5mm Stereo Mini-jack [8x Infrared Receiver]
Outputs
- 8x RJ45 [8x HDMI & Propriety Data]
- 8x 3.5mm Stereo Mini-jack [8x Infrared Emitter]
