- Supports 1 IR Learning input, 8 IR Blaster outputs, 8 Trigger inputs, 8 Relay outputs, 2 COM ports, and 4 Ethernet ports
- Supports an IR learning function which captures the IR signal broadcast by your remote when you press a button for retransmission as a part of a macro
- Supports trigger inputs with a voltage range of 0~15V (triggers at 5V)
- Supports Baud rates from 4800bps to 115200bps
- Supports 10/100 Ethernet network connections
Inputs
- 1x 3.5mm Stereo Mini-jack [1x IRL (IR Learning) Infrared Receiver]
- 8x 2-Pin Terminal Block [8x Trigger]
- 1x USB Type A [1x SERVICE Propriety Data]
Outputs
- 8x 3.5mm Stereo Mini-jack [8x Infrared Emitter]
- 2x 9-pin D-sub [2x RS-232 Data]
- 8x 2-Pin Terminal Block [8x Relay]
- 4x RJ45 [4x IP Control]
PSU:
- 5V/2.6A
Dimensions
- 432mm [W] x 181mm [D] x 49mm [H]
Net Weight
- 2186g
