- Supports 8 Relays, 8 PWM, 8 Voltage and 1 Definition outputs
- Reply supports close, open and toggle controls with LED illuminators and power up to 30V/DC, 10A
- PWM support 10 volt with 0~100% duty cycle adjustable
- Voltage outputs supports from 0~10 volt with adjustment from 0~100% (0, 0.1, 0.2 ~10 volt)
- Definition output supports RS-232/422/485 with adjustable baud rate
- DMX-512 data transmission up to 250 Kbaud/s with unidirectional, serial transmission and daisy-chain configuration up to 512 nodes of max time 22ms (roughly 44Hz)
- RS-232/Console supports up to 256 bytes per command
- Supports 5V/2.6A ~ 24V/1.2A DC power supply
- Supports USB and WebGUI firmware update
- Supports RS-232 and Telnet controls
- Control port supports PoE function
Inputs
- 1x RJ45 [1x IP Control]
- 1x 9-pin D-sub [1x RS-232 Data]
- 1x USB Type A [1x SERVICE Propriety Data]
Outputs
- 8x 2-Pin Terminal Block [8x Relay]
- 1x 5-Pin Terminal Block [1x RS-232/422/485/DMX512]
- 8x 2-Pin Terminal Block [8x PWM OUT (10V) Power Block]
- 8x 2-Pin Terminal Block [8x VOLTAGE OUT (0~10V) Power Block]
PSU:
- 5V/2.6A
Dimensions
- 200mm [W] x 95mm [D] x 31mm [H]
Net Weight
- 548g
