• HDMI 2.0 and DVI 1.0 compatible
• HDCP 2.2 and HDCP 1.x compliant
• 1 HDMI input
• 1 VGA input with 3.5mm mini-jack audio input
• Supports HDMI input resolutions up to 4K@60Hz (4:4:4, 8-bit)
• Supports VGA input resolutions up to WUXGA (RB)
• Simultaneous transmission of uncompressed video, audio and data over a single 100m Cat.5e/6/7 cable at 1080p and 70m at 4K
• Scaled HDBaseT output supports resolutions up to 4K@30Hz (4:4:4,8-bit)
• Automatic input selection with hot plug detection enabling hands-free operation
• Unit may be powered locally or via 48V PoH from a compatible HDBaseT Receiver (PSE)
• Wall plate is designed for EU two-gang sized enclosures
• Front panel LEDs indicate input selection, power and link status
• Controllable via front panel controls with an OSD or RS-232 (via the RS232 port on a compatible Receiver)
• USB port supports firmware update and charging of 5V/1A devices
