- Compatible with HDMI 2.0 , DVI 1.0, HDCP 2.2
- Supports PC input resolutions from VGA~WUXGA and HD input resolutions from 480i~1080p@60Hz
- Supports HDMI input resolutions 480i ~ 4K@60Hz (4:4:4, 8-bit)
- Supports HDMI output resolutions 640×480@60Hz ~ 4096×2160@60Hz (4:4:4, 8-bit)
- Analog YUV input is supported with the use of a 15-pin to 3-RCA adapter
- 50/60Hz frame rate conversion
- 3-D motion adaptive de-interlacing and 3:2/2:2 pull-down detection and recovery
- Can automatically detect and output the preferred resolution and refresh rate reported by the EDID of the connected display (NATIVE output mode)
- EDID management options including multiple pre-defined EDIDs and EDID pass-through
- Comprehensive output picture adjustments (contrast, brightness, hue, saturation, sharpness, RGB (color tone) level and aspect ratio size)
- Supports LPCM 2.0 digital/analog audio input and LPCM 2.0 digital/analog output. The audio source is selected via the OSD and output simultaneously over the HDMI, optical and phone jack connections
Inputs
- 1x HDMI [1x Uncompressed AV and Data]
- 1x 15-pin D-sub [1x PC/HD RGBHV / YPbPr Component]
- 1x TOSLINK [1x OPTICAL 2 Channel LPCM]
- 1x 3.5mm Stereo Mini-jack [1x Stereo(L/R)]
- 1x USB Type A [1x SERVICE Propriety Data]
Outputs
- 1x HDMI [1x Uncompressed AV and Data]
- 1x TOSLINK [1x OPTICAL 2 Channel LPCM]
- 1x 3.5mm Stereo Mini-jack [1x Stereo(L/R)]
PSU:
- 5V/2.6A
Dimensions
- 102mm [W] x 157mm [D] x 25mm [H]
Net Weight
- 340gr
