- Multiple input formats including HDMI, DisplayPort and VGA
- Compatible with HDMI 2.0, HDCP 2.2, HDCP 1.4 and DVI 1.0
- Supports resolution up to 4K@60Hz YUV 4:4:4 over the HDMI and DisplayPort inputs and over the HDMI output
- Auto source detection: Automatically switches to the most recently connected input
- Wide range of aspect ratio settings including: full screen, 16:9, 16:10 and 4:3
- Direct adjustment of contrast, brightness, hue and saturation
- Analog stereo audio output with volume control and audio mute function
- Supports EDID management
- Comprehensive user interface options including: Front panel with OSD, WebGUI, Telnet, RS-232, and IR remote
- Firmware can be updated via USB
Inputs
- 1x HDMI [1x Uncompressed AV and Data]
- 1x DisplayPort [1x Uncompressed Video]
- 1x 15-pin D-sub [1x VGA RGBHV]
- 1x 3.5mm Stereo Mini-jack [1x Stereo(L/R)]
- 1x 3.5mm Stereo Mini-jack [1x RS-232]
- 1x RJ45 [1x IP Control]
- 1x USB Type A [1x SERVICE Propriety Data]
Outputs
- 1x HDMI [1x Uncompressed AV and Data]
- 1x 3.5mm Stereo Mini-jack [1x Stereo(L/R)]
PSU:
- 5V/3A
Dimensions
- 231mm [W] x 117mm [D] x 25mm [H]
Net Weight
- 646gr
