- Compatible with HDMI, HDCP and DVI compliant
- Supports a wide range of PC resolutions from VGA to WUXGA (RB) and HD resolutions from 480i to 1080p
- Automatically detects the display settings of the connected display and outputs the correct resolution and refresh rate when the NATIVE output option is selected
- Supports adjustment of contrast, brightness, hue, saturation, sharpness, RGB (color tone) level and aspect ratio size of the video output
- Supports OSD selectable stereo analog and digital audio inputs and simultaneous stereo analog and digital audio outputs to HDMI, Optical digital audio and analog mini-jack connections
Inputs
- 1x 15-pin D-sub [1x PC/HD RGBHV / YPbPr Component]
- 1x 3.5mm Stereo Mini-jack [1x Stereo(L/R)]
- 1x TOSLINK [1x OPTICAL 2 Channel LPCM]
- 1x USB Type A [1x SERVICE Propriety Data]
Outputs
- 1x HDMI [1x Uncompressed AV and Data]
- 1x 3.5mm Stereo Mini-jack [1x Stereo(L/R)]
PSU:
- 5V/2.6A
Dimensions
- 102mm [W] x 157mm [D] x 25mm [H]
Net Weight
- 340gr
