- Motion adaptive 3-D de-interlacing and 3D Y/C separation with CVBS input
- Automatic 2:2/3:2 film mode detection and correction
- Automatic NTSC/PAL video format detection and frame rate conversion (from 50Hz to 60Hz)
- Automatic 3D noise reduction
- Supports one dimensional CTI (Chroma Transient Improvement) and LTI (Luminance Transient Improvement) for edge improvement
- OSD menu for picture quality adjustment
- Supports HD timings from 480p@60 Hz to 1080i/p@60 Hz and PC timings from VGA@640×480 to WUXGA@1920×1200
- Two ways to control the CM-1392M, either using an IR remote control or the control panel on the device
Inputs
- 1x RCA [1x Composite Video]
- 1x S-Video [1x S-video]
- 2x RCA [1x Stereo (L/R)]
Outputs
- 1x HDMI [1x Uncompressed AV and Data]
PSU:
- 5V/1A
Dimensions
- 125mm [W] x 123mm [D] x 30mm [H]
Net Weight
- 400gr
