- Supports SD-SDI, HD-SDI and 3G-SDI input signals with auto-detection
- Supports PC/HD and SDI (bypass) output simultaneously
- SDI interface operates at bitrates of 2.970 Gbit/s, 2.970/1.001 Gbit/s, 1.485 Gbit/s, 1.485/1.001 Gbit/s and 270 Mb/s
- Supports SDI input/output distance up to 100 meters (3G-SDI), 200 meters (HD-SDI), or 300 meters (SD-SDI)
- Scale any SDI signal to PC/HD, PC timings support VGA@60 Hz~WUXGA@60 Hz (RB) and HDTV timings support 480i/576i~1080p@50/60 Hz
- Supports SD-SDI SMPTE 259M-C, at bitrates of 270 Mbit/s; HD-SDI SMPTE 292M, at bitrates of 1.485 Gbit/s and 1.485/1.001 Gbit/s; 3G-SDI SMPTE 424M/425M-A, at bitrates of 2.970 Gbit/s and 2.970/1.001 Gbit/s
- Equalized and re-clocked loop output
- Alternative audio output to coaxial and analog 2CH
Inputs
- 1x BNC [1x 3G-SDI]
Outputs
- 1x BNC [1x Loop Output 3G-SDI]
- 1x 15-pin D-sub [1x RGBHV / YPbPr Component]
- 1x RCA [1x Coax 2 Channel LPCM]
- 2x RCA [1x Stereo (L/R)]
PSU:
- 5V/2.6A
Dimensions
- 180mm [W] x 142mm [D] x 25mm [H]
Net Weight
- 435gr
