Seamless mixing 4K and HD outputs
Designed for professional video projects, the Image2K graphics card is a highly scalable graphics card for use with multiple screen or projector installations.
Designed to power multi-screen, video wall and LED installations, the Image2K enables seamless mixing of 4K and HD outputs, all at 60 frames per second over direct HDMI outputs.
Fully integrated with Datapath’s graphical setup wizard, the Image4K is easy to configure for different combinations of monitors, projectors, or LED controllers. Output resolution, rotation and wall layout are all easily configured using the intuitive graphical interface in a matter of minutes.
With outputs synchronized across all cards, multiple video walls and single screen displays can be powered from a single system, making the Image2K ideal for security suites, corporate office displays, retail signage or multi-video wall applications. Systems built using Datapath’s VSN or iolite 600 chassis can use up to 8 Image2K cards, giving a total of 32 HD outputs, 16 4K outputs, or a mixture of the two.
Software Drivers
Datapath’s multi-screen display driver is engineered specifically for use with Windows 10 and Windows Server 2019. The display driver unifies multiple Image2K cards to present a single desktop canvas to the Windows operating system, allowing each video wall to display hundreds of output windows with full support for picture-in-picture and overlaps. The multi-screen driver supports a maximum of 32 outputs for the Image2K (eight cards).
Display Driver Configuration Tool
Our unique graphical setup tool allows users to easily configure multiple outputs to create complex video wall layouts in a matter of minutes. The tool guides users through the setup process using a simple step-by-step wizard, enabling screen dimensions, resolution and position to be configured with ease. The built-in database of monitors contains hundreds of models from various manufacturers, allowing supported resolutions and bezel measurements to be easily configured for each monitor.
Control Software
The Image2K is fully compatible with Datapath’s WallControl 10 software, which provides users with the interface required to quickly and effectively manage content that can include video captures, IP streams and local applications. Users are able to place any input source on any part of the Video Wall using a simple drag and drop interface. Precise positioning of each piece of content can be achieved through the mouse and keyboard, or via the revolutionary template tool.
