APPLICATION
Measurement Electromagnetic field
-
Electromagnetic field
-
Electric field
-
RF strength field
FEATURES
-
4 digits, 2.4 inches color TFT LCD.
-
3 measurements in one meter:
-
Electromagnetic Field ( 3 – axis ).
-
Electric Field.
-
RF Strength Field.
-
Data Hold (HOLD).
-
Language Selection (choose your language):
-
English; Traditional Chinese; Simplified Chinese;
-
Japanese; Spanish.
SPECIFICATIONS
-
Sample rate: 6 seconds per time.
-
Battery life: approximate 8 hours.
-
Audible key tone alarm: buzzer
-
Operating temperature & humidity: 5°C~40°C, below 80% RH.
-
Storage temperature & humidity: -10°C~60°C, below 70%.
-
Weight: about 120g.
-
Dimensions: 115(L) x 60(W) x 21(H) mm.
Electrical specifications
|
Specifications
|
Electromagnetic field
|
Electric field
|
RF strength field
|
|
Sensor type
|
Low frequency
Magnetic field
Triple axis (X,Y,Z)
|
LF electric field
|
RF strength
|
|
Range
|
0.02~2000mG,
0.02~200µT
|
50V/m~2000 V/m
|
0.2µW/m²~554 mW/m²
|
|
Resolution
|
0.01 /0.1 1 mG or
0.01/0.1/1µT
|
1 V/m
|
0.2µW/m², 0.02µA/m,
0.2mV/m, 0.02µW/cm², 1dB
|
|
Frequency
|
50/60 Hz
|
50/60Hz
|
50 MHz~3.5 GHz
|
|
Accuracy
|
± (15%+100 dgt)
|
± (7%+50 dgt)
|
±2 dB at 2.45 GHz
|
ACCESSORIES
-
User’s manual
-
1.5VAAA alkaline battery
-
Carrying case.
