APPLICATION
Easy for holding according to the best design to fit human body engineering, with the optimum inclined view angle
Easy for holding according to the best design to fit human body engineering, with the optimum inclined view angle
DCV
|
||||
Rnge
|
Resolution
|
Accuracy
|
Input impedance
|
Overload Protection
|
200mV
|
100μV
|
±(0.5%+1)
|
10MΩ
|
DC 1000V
AC 750V rms |
2V
|
1mV
|
±(0.5%+3)
|
||
20V
|
10mV
|
|||
200V
|
100mV
|
|||
1000V
|
1V
|
ACV | ||||
Range | Resolution | Accuracy 40Hz~500Hz |
Input impedance | Overload Protection |
200mV | 100μV | ±(1.2%+4) | 10MΩ | DC 1000V AC 750V rms |
2V | 1mV | |||
20V | 10mV | |||
200V | 100mV | |||
750V | 1V | ±(1.5%+4) |
DCA
|
||||
Range
|
Resolution
|
Accuracy
|
Voltage Burden
|
Overload
Protection |
200μA
|
100nA
|
±(1.2%+2)
|
<0.7V
|
0.5A/250V
fuse |
2mA
|
1μA
|
|||
20mA
|
10μA
|
|||
200mA
|
100μA
|
|||
10A
|
10mA
|
±(2.5%+2)
|
<0.3V
|
10A/250V fuse
|
ACA
|
||||
Range
|
Resolution
|
Accuracy
40Hz~500Hz |
Voltage Burden
|
Overload Protection
|
200μA
|
100nA
|
±(1.5%+3)
|
<0.7V
|
0.5A/250V fuse
|
20mA
|
10μA
|
|||
200mA
|
100μA
|
|||
10A
|
10mA
|
±(2.5%+3)
|
<0.3V
|
10A/600V fuse
|
Frequency Test (Auto Ranging) | ||||
Range | Resolution | Accuracy | Max.sensitivity | Overload Protection |
2KHz | 1Hz | ±(0.8%+3) | Lo:500mVrms 10K-1MHz 5Vrms 1MHz-20MHz Hi:2Vrms 10-100KHz |
DC/AC 350Vrms |
20KHz | 10Hz | |||
200KHz | 100Hz | |||
2MHz | 1KHz | |||
20MHz | 10KHz |
Diode Test
|
||||
Range
|
Resolution
|
Measuring
Voltage |
Measuring
Current |
Overload Protection
|
/ |
1mV
|
3.3Vmax
|
0.7mA
|
DC/AC 500V rms
|
Transistor (HFE) Test:
|
||||
Range
|
Measurement
Range |
Measuring
Voltage |
Measuring Current
|
Overload
Protection |
NPN PNP
|
0~1000
|
<3.2V
|
IB ≒0.7mA
|
─────
|
Continuity Test:
|
||||
Range
|
Resolution
|
Sound level Voltage
|
open-circuit
Protection |
Overload Protection
|
/ |
0.1Ω
|
75Ω below
|
MAX 3.3V
|
DC/AC 500V rms
|
Resistance Test | ||||
Range | Resolution | Accuracy | Open-circuit Votlage |
Overload Protection |
200Ω | 0.1Ω | ±(1.2%+4) | MAX 3.3V | DC/AC 500V rms |
2KΩ | 1Ω | ±(1.0%+2) | >0.3V | |
20KΩ | 10Ω | |||
200KΩ | 100Ω | |||
2MΩ | 1KΩ | |||
20MΩ | 10KΩ | ±(2%+5) |
Capacitance Test
|
||||
Range
|
Resolution
|
Accuracy
|
Measuring
Frequency |
Overload
Protection |
2nF
|
1pF
|
±(5%+10)
|
≒200Hz/1.5sec
|
0.5A/250V fuse
|
20nF
|
10pF
|
|||
2μF
|
1nF
|
|||
20μF
|
10nF
|
|||
2000μF
|
1μF
|
≒2Hz/8sec
|
Inductance Test
|
||||
Range
|
Resolution
|
Accuracy
|
Open-circuit
Voltage |
Overload
Protection |
2mH
|
1μ
|
±(5%+10)
|
≒1000Hz
|
0.5A/250V Fuse
|
20mH
|
10μ
|
|||
200mH
|
100μ
|
≒200HZ
|
||
2H
|
1mH
|
|||
20H
|
10mH
|
