UT200A
Digital Clamp Meter

UT200A 2000-count digital clamp meter is suitable for daily repair and maintenance of household equipment especially by electricians, featuring Min 2A AC current measurement.

Features of UT200A Digital Clamp Meter

  • Display count: 2000
  • Jaw opening: 28mm

SPECIFICATIONS

Specifications of UT200A Digital Clamp Meter

Specifications Range UT200A
AC current (A) 2A/20A/200A ±(1.5%+5)
20A/200A/600A
AC voltage (V) 600V ±(1.5%+5)
DC voltage (V) 600V ±(1%+3)
Resistance (Ω) 20kΩ ±(1%+4)
Features
Display count 2000
Manual range √
Jaw capacity 28mm
Diode test √
Buzzer continuity √
Low battery indication √
Data hold √
LCD backlight √
Input impedance ≥10MΩ √
General Characteristics
Power 9V (6F22)
LCD size 35.6mm × 18mm
Product color Red and grey
Product weight 260g
Product size 208mm × 76mm × 30mm
Standard accessories Probes, battery, carrying bag
Standard individual packing Gift box, manual
Standard quantity per carton 40pcs
Standard carton size 540mm × 490mm × 335mm
Standard carton gross weight 23kg
