Advanced function
Channel power, Time domain power, Occupies bandwidth, Third order intermodulation, Adjacent channel power, Spectrum Monitoring, Carrier-to-noise ratio, Harmonic
EMI Pre-compliance analysis
Optional components, together with near-field probes, help you find and improve EMI defects in advance
10.1 inch HD capacitive touch screen
The screen is large and high-definition. Multi touch, easy to operate
Rich detector functions
Positive peak, Negative peak, Sampling, Standard, Average, Quasi-peak
4 traces
4 traces are provided to facilitate comparative observation and find abnormal signals. Intuitive test and convenient operation
10001 scan points
Scan 10001 points to display details more clearly. Effectively capturing abnormal signals
Excellent selectivity
It has stronger signal resolution capability of adjacent unequal amplitudes
DANL <-161dBm
The spectrum analyzer has low bottom noise and more accurate measurement. Small signal can be accurately measured
| Model | Frequency Range | RBW | Phase Noise | DANL | Trace Source | Display |
|---|---|---|---|---|---|---|
| UTS1015B | 9kHz~1.5GHz | 1Hz~1MHz | -98dBc/Hz @10kHz | -161dBm | NO | 10.1 inch TFT LCD |
| UTS1015T | 9kHz~1.5GHz | 1Hz~1MHz | -98dBc/Hz @10kHz | -161dBm | YES | 10.1 inch TFT LCD |
| UTS1032B | 9kHz~3.2GHz | 1Hz~1MHz | -98dBc/Hz @10kHz | -161dBm | NO | 10.1 inch TFT LCD |
| UTS1032T | 9kHz~3.2GHz | 1Hz~1MHz | -98dBc/Hz @10kHz | -161dBm | YES | 10.1 inch TFT LCD |
